Product description
Operating table with accessories mainly intended for fistula repair surgery and other gynaecological surgical procedures. Mechanical and manual-hydraulic operating table of strong and sturdy structure in 4 sections.
Specifications
Mechanical manual-hydraulic
Mobile stainless steel base on ball bearing castors with central brake
Divided in four sections (4): head, torso, pelvic and legs
All sections fitted with antistatic radiolucent mattress, detachable for easy cleaning
Adjustable head section +20 to โ 90 degrees
Adjustable torso, pelvic and leg sections
Detachable leg section
Adjustable to the following positions: Trendelenburg position (40-60 degrees); reverse Trendelenburg position; flexion, extension and lateral tilt both sides (20 degrees); lithotomy position; proctology position
When elevated and fully extended all sections align to perfectly flat surface (supine position)
Radiolucent table top with integrated standard size X-ray cassette channel
Height adjustable by hydraulic foot operated pedal: 75cm to 1,05m
Table top rotation independent of base, 360 degrees
Mechanical operated control or crank handles for three sections: back, pelvic, legs with auto locking gear mechanism
Material
Frame:
Austenitic stainless steel or chrome plated steel, smooth finishing for easy cleaning
High resistant to corrosion and cleaning agents
Sliders/fixtures for accessories:
Stainless steel welded to the table frame
Mattress:
Seamless rubber, highly tear resistant, liquid proof and washable
Antistatic
Flame retardant
Decontaminant resistant
Dimensions
Overall: 190-230 cm X 50-60 cm x 75-105 cm (length x width x height)
Carrying capacity: 130-150 kg
Supplied with
Detailed step by step pictorial based instructions for assembly and use
Operating manual (instruction manual) and installation manual
1 x set of tools required for assembly
2 x shoulder support.
1 x spare set of 4 fixation clamps.
1 x set fitting mattresses.
Set of accessories, each with fixation clamp:
1 x anaesthesia screen.
2 x thigh support.
2 x thigh support.
2 x arm board, with arm strap.
2 x knee support, lithotomy crutch, with strap.
1 x body strap.
1 x foot rest for proctology position
List of all parts supplied with the operating table.
Packaging, labelling, instructions
One (1) unit per box
Identify Packaging Standards and provide Packaging Test ReportsDimensions: Unit Weight in Kg (including its packaging)
Unit Volume in M3 (including its packaging)
Dimensions of box, length x width x height in cm
Labelling:
Compliance with EAN 128 bar code requirements
Operating table with accessories mainly intended for fistula repair surgery and other gynaecological surgical procedures. Mechanical and manual-hydraulic operating table of strong and sturdy structure in 4 sections.
Specifications
Mechanical manual-hydraulic
Mobile stainless steel base on ball bearing castors with central brake
Divided in four sections (4): head, torso, pelvic and legs
All sections fitted with antistatic radiolucent mattress, detachable for easy cleaning
Adjustable head section +20 to โ 90 degrees
Adjustable torso, pelvic and leg sections
Detachable leg section
Adjustable to the following positions: Trendelenburg position (40-60 degrees); reverse Trendelenburg position; flexion, extension and lateral tilt both sides (20 degrees); lithotomy position; proctology position
When elevated and fully extended all sections align to perfectly flat surface (supine position)
Radiolucent table top with integrated standard size X-ray cassette channel
Height adjustable by hydraulic foot operated pedal: 75cm to 1,05m
Table top rotation independent of base, 360 degrees
Mechanical operated control or crank handles for three sections: back, pelvic, legs with auto locking gear mechanism
Material
Frame:
Austenitic stainless steel or chrome plated steel, smooth finishing for easy cleaning
High resistant to corrosion and cleaning agents
Sliders/fixtures for accessories:
Stainless steel welded to the table frame
Mattress:
Seamless rubber, highly tear resistant, liquid proof and washable
Antistatic
Flame retardant
Decontaminant resistant
Dimensions
Overall: 190-230 cm X 50-60 cm x 75-105 cm (length x width x height)
Carrying capacity: 130-150 kg
Supplied with
Detailed step by step pictorial based instructions for assembly and use
Operating manual (instruction manual) and installation manual
1 x set of tools required for assembly
2 x shoulder support.
1 x spare set of 4 fixation clamps.
1 x set fitting mattresses.
Set of accessories, each with fixation clamp:
1 x anaesthesia screen.
2 x thigh support.
2 x thigh support.
2 x arm board, with arm strap.
2 x knee support, lithotomy crutch, with strap.
1 x body strap.
1 x foot rest for proctology position
List of all parts supplied with the operating table.
Packaging, labelling, instructions
One (1) unit per box
Identify Packaging Standards and provide Packaging Test ReportsDimensions: Unit Weight in Kg (including its packaging)
Unit Volume in M3 (including its packaging)
Dimensions of box, length x width x height in cm
Labelling:
Compliance with EAN 128 bar code requirements
| Pack Size | Avg. Price |
|---|---|
| Each | $2,823.40 |
